4 Hole Button Machine Screw

///4 Hole Button Machine Screw
  • 4HBMS

4 Hole Button Machine Screw

▶ Material:stainless steel & carbon steel
▶ Security Level:
▶ Size: M3-M6
▶ Standard: DIN, ANSI, JIS, BS
▶ Length:  4mm-80mm
▶ Packing: Boxs or pallet or customer request

skype chat
Category: Tag:

▶ 4 Hole security screws is similar to 2 hole/ 3 hole screw
▶ 4 Hole drilled into the head require a unique 4-pin driver to install and remove
▶ Aesthetically pleasing head design, often specified by designers and architects
▶ Button head gives a raised finish (screw length excludes head height)
▶ Manufactured in A2 stainless steel or carbon steel or customer request
▶ Suitable for low torque applications
▶ Matching driver bits available
▶ For customer request

Size Driver Size Head Dia Head Height
M3 Custom 5.5mm 1.5mm
M4 Custom 7.4mm 2.1mm
M5 Custom 9.3mm 2.7mm
M6 Custom 10.4mm 3.2mm
