5-Lobe Pin Countersunk Machine Screw

///5-Lobe Pin Countersunk Machine Screw
  • 5LPCMS

5-Lobe Pin Countersunk Machine Screw

▶ Material:stainless steel & carbon steel
▶ Security Level:
▶ Size: M3-M6
▶ Standard: DIN, ANSI, JIS, BS
▶ Packing:Boxs or pallet or customer request
▶

skype chat
Category: Tag:

▶ 5-Lobe Pin also known as: Torx-Plus
▶ 5-Lobe Pin screws with a central pin inside the five-lobe recess preventing removal with standard Torx tools
▶ Countersunk head for a flush finish in a countersunk hole (screw length includes head)
▶ Manufactured in A2 stainless steel or carbon steel
▶ Suitable for higher torque applications
▶ Matching security insert bits and L-Keys available

Size Driver Size Head Dia Head Height
M3 10IPR 5.6mm 1.7mm
M4 15IPR 7.8mm 2.3mm
M5 20IPR 9.8mm 2.8mm
M6 25IPR 11.6mm 3.3mm
