Phill Pin Button Machine Screw

///Phill Pin Button Machine Screw
  • PPBMS

Phill Pin Button Machine Screw

▶ Material:stainless steel & carbon steel
▶ Security Level:
▶ Size: M3-M6
▶ Standard: DIN, ANSI, JIS, BS
▶ Packing:Boxs or pallet or customer request
▶

skype chat
Category: Tag:

▶ Phill Pin screw has a Philips (cross) recess with a pin in the centre
▶ Cannot be removed with Phillips Screwdriver
▶ Countersunk head for a flush finish in a countersunk hole (screw length includes head)
▶ Manufactured in A2 stainless steel or carbon steel
▶ Suitable for higher torque applications

Size Driver Size Head Dia Head Height
M3 #1 5.5mm 1.5mm
M4 #2 7.4mm 2.1mm
M5 #2 9.2mm 2.7mm
M6 #3 10.4mm 3.2mm
