Phill Pin Countersunk Machine Screw

///Phill Pin Countersunk Machine Screw
  • PPCMS

Phill Pin Countersunk Machine Screw

▶ Material:stainless steel & carbon steel
▶ Security Level:
▶ Size: M3-M6
▶ Standard: DIN, ANSI, JIS, BS
▶ Packing:Boxs or pallet or customer request
▶

skype chat
Category: Tag:

▶ Phill Pin screw has a Philips (cross) recess with a pin in the centre
▶ Cannot be removed with Phillips Screwdriver
▶ Countersunk head for a flush finish in a countersunk hole (screw length includes head)
▶ Manufactured in A2 stainless steel or carbon steel
▶ Suitable for higher torque applications

Size Driver Size Head Dia Head Height
M3 #1 5.6mm 1.7mm
M4 #2 7.8mm 2.3mm
M5 #2 9.8mm 2.8mm
M6 #3 11.6mm 3.3mm
